KEXINT GJDFBH Indoor Flat Ribbon Fiber Optic Cable 2-12 Cores SM MM

KEXINT GJDFBH Indoor Flat Ribbon Fiber Optic Cable 2-12 Cores SM MM

Product Details:

Place of Origin: CHINA
Brand Name: KEXINT
Certification: CE Iso-9001 Ross UL
Model Number: GJDFBH

Payment & Shipping Terms:

Minimum Order Quantity: 1+km
Price: 184.35+$+km
Packaging Details: box
Delivery Time: 10
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram, MoneyGram
Supply Ability: 1000+KM+Day
Get Best Price Contact Now

Detail Information

Color: Yellow...optional Outsheath: PE,LSZH,PVC
Fiber Count: 1-12 Cores Fiber Type: SM/MM
Strength Member: Aramid Yarn Application: Indoor
Storage Temperature: -60~+80℃
High Light:

Flat Ribbon Fiber Optic Cable

,

GJDFBH Fiber Optic Cable

,

12 Cores Indoor Fiber Optic Cable

Product Description

KEXINT 2-12 Cores SM MM GJDFBH Indoor Flat Ribbon Fiber Optic Cable





Indoor optical cables are optical cables laid in buildings and are mainly used for communication equipment, computers, switches and end-user equipment in buildings. in order to convey information.


Fiber:Up to12.

Fiber Types: Single-mode or multimode

Cable Types: Ribbon fiber

Strength Member: Aramid yarn

Sheath Options: Single LSZH/PVC sheath

Operating Temperature:-20C~+70C

Compliances: In Accordance with IEC, ITU and EIA standards



Features:

High fiber density, small size, light weight, good looking and compact structure; .
Easy for installation and spicing, branching and flame retardant;

All dielectric structure design, without electromagnetic induction effect. High-strength aramid fiber reinforcements ensure that the optical fiber has no tensile strain and ensure long-term stability of optical fiber transmission characteristics;

Tight-buffered optical cables can be directly connected without transition joint boxes and pigtails, which is very suitable for construction operations and easy maintenance.



Applications:

Indoor cabling;
Ribbon patch cord and ribbon pigtail;
As flexible connection cable between equipments.

Technical Specification:
Cable type
Fibercounts
Cable dimension
(mm)
Tensile Strength(N)
Crush Resistance( N/10omm)
Minimum bend radius(mm)
Short term
Long term
Short term
Long term
Dynamic
static
GJDFH(V)
4
2.2×3.2
220
100
500
250
30H
15H
GJDFH(V)
6
2.2x4.2
220
100
500
250
30H
15H
GJDFH(V)
8
2.2x4.2
220
100
500
250
30H
15H
GJDFH(V)
12
2.2x4.7
220
100
500
250
30H
15H
KEXINT GJDFBH Indoor Flat Ribbon Fiber Optic Cable 2-12 Cores SM MM 0
KEXINT GJDFBH Indoor Flat Ribbon Fiber Optic Cable 2-12 Cores SM MM 1
