FTTH Outdoor IP65 PLC Fiber Optic Distribution Box Telecom Comunication
Product Details:
| Place of Origin: | China |
| Brand Name: | KEXINT |
| Certification: | CE/ROHS/ISO9001 |
| Model Number: | KXT-B-16G |
Payment & Shipping Terms:
| Minimum Order Quantity: | 500 pieces |
|---|---|
| Price: | USD 8.69~11.66 pieces |
| Delivery Time: | 5-8 work days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 10000 Piece/Pieces per Week |
|
Detail Information |
|||
| Application: | Telecom Comunication | Jacket: | PVC PE |
|---|---|---|---|
| Color: | Grey | Type: | Fiber Optical Distribution Box |
| High Light: | PLC Fiber Optic Distribution Box,FTTH Fiber Optic Distribution Box,Outdoor IP65 FTTH Distribution Box |
||
Product Description
FTTH Outdoor IP65 PLC Fiber Optic Distribution Box Telecom Comunication
KEXINT FTTH KXT-B-16G 16 Ports Outdoor IP 65 PLC Grey Fiber Optic Distribution Box
Products Description:
KXT-B-16G fiber access termination closure is able to hold up to 16 subscribers and 96 splicing points as closure.it is used as a splicing closure and a termination point for the feeder cable to connect with drop cable in FTTXnetwork system. It integrates fiber splicing, splitting, distribution, storage and cable connection in one solidprotection box
Features:
1. Water-proof design with IP-65 Protection Level.
2. Integrated with flap-up splice cassette and adapter holder.
3. All stainless metal plate and anti-rusting bolts, nuts
4. Fiber bend radius control more than 40 mm
5. Suitable for the fusion splicer or mechanical splice.
6. 2 pieces of 1*8 splitter can be installed as an option.
7. Mechanical sealing structure and mid-span cable entry.
8. 16 ports cable entrance for drop cable
9. 16 adapter for drop cable patching
Specification:
| Model Number | KXT-B-16G |
| IP Level | IP 65 |
| Max Capacity | 2 pcs 1*8 PLC |
| Mounting Way | Wall/Pole mounting |
| Material | PC/ABS |
| Size | 287*172*102 mm |
| Color | Grey/Black |
| Cable Diameter | 18 mm(Max) |
| Port Count | 4 into 16 out |
